WEIGHT V200
Tire Introduction
> Longitudinal winding grooves ensure better traction in high speed
> Deep grooves design improve mileage
> Excellent wear resistance play a strong driving power on the wet/mud road
Main Feature
> THREE WINDING SIPES
Enhance water evacuation, improve traction in wet condition with the design of lateral block pattern
> WIDE TREAD DESIGN
Enlarge landing area, keep stable and improve wear resistance
> MEW RUBBER FORMULA
Provide better wear resistance, save energy and more environmental
> TIRE CARCASS REINFORCE
Reinforce carcass structure and adopt special formula, to achieve excelent load capacity and be more economic
| SIZE | P.R |
LOAD INDEX |
SPEED INDEX |
RIM |
S.W. mm |
O.D. mm |
MAX LOADING |
MAX PRESSURE |
||||
| SINGLE | DOUBLE | |||||||||||
| 155R12C | 6PR | 83/81 | N |
4.50B | 157 | 550 | 560 | 1235 | 530 | 1168 | 450 |
65 |
| 165R13C | 6PR | 91/89 | P | 4.50B | 167 | 596 | 615 | 1360 | 580 | 1280 | 375 | 54 |
| 165R14C | 6PR | 93/91 | P | 4 1/2J | 167 | 596 | 650 | 1430 | 615 | 1360 | 375 | 54 |
| 185R15C | 8PR | 103/102 | Q | 5 1/2J | 188 | 674 | 875 | 1929 | 850 |
1847 | 450 | 65 |
| 175R13C | 8PR | 97/95 | Q | 5.00B | 177 | 610 | 730 | 1609 | 690 | 1521 | 450 | 55 |
| 175/70R14C | 8PR | 95/93 | S |
5J | 177 | 602 | 690 | 1521 | 650 | 1433 | 375 | 54 |
| 185R14C | 8PR | 102/100 | R | 5 1/2J | 188 | 650 | 850 | 1874 | 800 | 1764 | 450 | 65 |
| 195R14C | 8PR | 106/104 | R | 5 1/2J | 198 | 666 | 950 | 2094 | 900 | 1984 | 450 | 65 |
| 205R14C | 8PR | 109/107 | Q | 6J | 208 | 686 | 1030 | 2271 | 975 | 1984 | 450 | 65 |
| 195R15C | 8PR | 106/104 | R |
5 1/2J | 198 | 690 | 950 | 2094 | 900 | 1874 | 450 | 65 |
| 195/70R15C | 8PR | 104/102 | R | 6J | 201 | 655 | 900 | 1984 | 850 | 1984 | 450 | 65 |
| 205/70R15C | 8PR | 106/104 | R | 6J | 209 | 669 | 950 | 2094 | 900 | 1984 | 450 | 65 |
| 215/70R15C | 8PR | 109/107 | R | 6 1/2J | 221 | 683 | 1030 | 2271 | 975 | 2149 | 450 | 65 |
| 225/70R15C | 8PR | 112/110 | R | 6 1/2J | 228 |
697 | 1120 | 2469 | 1060 |
2337 | 450 | 65 |
| 5.00R12LT | 10PR | 87/85 | K | 3.50B | 143 | 568 | 545 | 1201 | 515 | 1135 | 450 | 65 |
